Ready-To-Go Angle Kit Stage 2 – S14/S15 (MCR Zombie)

Everything you need to add serious steering angle to your S14 / S15 — matched parts that work together, in one order.

Stage 2 built around the MCR Factory Zombie Knuckle, a cast drift knuckle designed by D1 driver Masashi Yokoi. It reaches about 65° of lock without moving the steering rack, following MCR's recommended setup: 35mm extended lower arms, D-MAX 30mm extended ball joint tie rod ends and clearance-type tension rods.

What's included

• MCR Factory Zombie Knuckle (pair)
• Kazama Auto Super Extended Front Lower Arms, +35mm (pair)
• D-MAX D1SPEC Reinforced Tie Rods Type R + 30mm Extended Ball Joint Tie Rod Ends, M14 (pair)
• D-MAX D1SPEC Pillow Ball Tension Rods, Offset Type Ver.3 (pair)
• GKTECH Braided Brake Lines — longer front lines for big steering angle

Who it's for

Intermediate drivers who want more angle and faster throttle-on than a bolt-on knuckle gives, without relocating the steering rack.

Fitment

Nissan S14 / S15 Silvia (240SX S14). Coilovers required.

Before you order

• MCR setup: remove the front sway bar, keep the rack in the stock position (no rack adapter), use 20–30mm wheel spacers, and fit a front stopper if you left-foot brake.
• Brake lines fit factory S14 240SX (1-piston) and S15 Silvia (4-piston) calipers. Running Z32 / Skyline brakes? Contact us and we'll swap in the GKTECH Z32 conversion lines.
• For off-road / competition use only.
• Prices include U.S. import duties — no surprise charges at delivery. Shipping and sales tax (where applicable) are calculated at checkout.
• All KZY123 kits use M14-thread tie rods, the same as the S14. We recommend M14 tie rods for non-HICAS S15s as well (the factory non-HICAS S15 uses M12).
