D-MAX Rear suspension, one side only / RACING SPEC (for GT-R rear knuckle)

D-MAX Rear suspension, one side only / RACING SPEC (for GT-R rear knuckle)

$570.99 USD
$570.99 USD
Sale Sold out
Shipping calculated at checkout.
Configuration

A service part for replacing the RACING SPEC rear suspension (GT-R rear knuckle compatible) as an assembly.

The GT-R rear knuckle compatible version of the RACING SPEC suspension. Most top competitors switch to the stronger, lighter GT-R knuckle, but GT-R parts don't bolt directly onto a Silvia, so we created a RACING SPEC version made for GT-R knuckles.


■ Compatible chassis codes


Chassis code CS14/S14/S15

Specifications / Rear


Inverted / conventional Conventional
Main spring free length 220mm
Main spring rate 9Kgf/mm
Main spring type Linear
Main spring inner diameter 62Ф
Upper mount Pillow ball
Length adjustment method Fully threaded
Damping adjustment method Dial type
Damping adjustment 30-step

Compatible knuckles


Compatible knuckles (aluminum) BCNR33/BNR34

*2-way independent adjustment of rebound and compression
